DA7212 I2S Audio Board For Raspberry Pi, Stereo Encoding/Decoding, Onboard Dual Microphones, Compatible With Raspberry Pi Series Boards

DA7212 I2S Audio Board For Raspberry Pi, Stereo Encoding/Decoding, Onboard Dual Microphones, Compatible With Raspberry Pi Series Boards

SKU:34213

Thương hiệu:Waveshare

(Chưa có bình luận)

598,000VND

Đặt hàng trước

Giá chưa bao gồm thuế giá trị gia tăng (VAT)

Sản phẩm đã bao gồm LOA 8Ω 5W

Sản phẩm nhập khẩu chính hãng từ Waveshare

Hỗ trợ kỹ thuật trong quá trình sử dụng

Sản phẩm được bảo hành 06 tháng

Thông tin sản phẩm

DA7212 I2S Audio Board For Raspberry Pi, Stereo encoding/decoding, Onboard dual microphones, Supports rich audio processing functions, compatible with Raspberry Pi series boards

Name: DA7212 I2S Audio Board For Raspberry Pi, Stereo Encoding/Decoding, Onboard Dual Microphones, Compatible With Raspberry Pi Series Boards
Brand: Waveshare
SKU: 34213
Price: 598000 VND
Availability: InStock
Rating: 5 (1 reviews)

DA7212 I2S Audio Board for Raspberry Pi

Supports stereo encoding/decoding and rich audio processing functions

Features

Based on Raspberry Pi 40PIN GPIO header, compatible with Raspberry Pi series boards
Adopts DA7212 professional stereo DAC chip, controlled through I2C, with audio transmitted via I2S interface
Onboard standard 3.5mm headphone jack, supports audio playback via external headphones
Onboard AUX input connector for easy connection to other devices
Onboard speaker screw terminal and dual channels PH2.0 speaker header, compatible with multiple application scenarios
Onboard dual microphones allow for recording without connecting any additional devices
Onboard programmable button and indicators for custom functions
Supports sampling frequency up to 96KHz
Supports up to 24-bit resolution audio data

Specifications

Audio Codec Chip	DA7212	DAC SNR	100dB
Power Supply	5V	ADC SNR	90dB
Logic Voltage	3.3V	Headphone Driver	160mW (16Ω at 5V)
Control Interface	I2C	Speaker Driver	2.6W per channel (4Ω BTL)
Audio Interface	I2S
